Merkjabreyta MM LC Duplex 1.25Gbps

Description

1.25 Gbps SFP Module, Multimode, HP-compatible LC Duplex Connector, 850nm, up to 550m, HP Aruba

The plug and play fiber connection
-The Plug & Play fiber optic link enables quick installation
-Sends data in high quality and additionally provides excellent reliability
-Distance up to 0,55km at a maximum data rate of 1.25Gbps
-Operating temperature: 0 °C ~ 70 °C

The DIGITUS® mini GBIC (SFP) transceiver modules offer highest quality and reliability. Wether from switch to switch, converter to switch, converter to converter or any else application: The wide product range of DIGITUS® modules makes possible a flexible usage of the fiber technology. The conformity to the MSA (Multi Source Agreement) standard ensures a compatibility to third party manufacturers.

Technical Details
-HP compatible
-HP-Aruba compatible
-Mini GBIC SFP (Small Form Factor Pluggable) module
-High quality and excellent reliability
-1.25 Gbps Maximum Data Rate
-Compliant to IEEE 802.3z Gigabit Standard
-Class 1 laser product compliant with EN 60825-1
-Easy plug-and-play installation
-MSA (Multi Source Agreement) compliant
-Hot pluggable
-Connector: 1x LC Duplex
-1000Base-SX - For Short Haul
-Wavelength: 850nm
-Transmission power: minimum -8 dBm, maximum -3 dBm
-Sensitivity Receiving Power: Minimum -20 dBm
-For a Distance of up to 0.55km
-Suitable for 50/125µm and 62.5/125µm multimode fiber cables
-Safe fast-locking mechanism
-Operating temperature: 0 °C ~ 70 °C
-Broadcasting Mode: Unidirectional
-Manufacturer compatibility: HP, Universal (MSA)
-Connector: LC
-DDM Support: no
-Distance (km): 0.5
-Mode: Multimode
-Ethernet speed: Gigabit
-Wavelength: 850 nm
