Klippur HTBS BASIC S 3010

Mesta þykkt ál: 1.6
Mesta þykkt stál: 1.2
Loftnotkun: ca. 420l/mín
Hámarksþrýstingur: 6.3bör
Þyngd: 1.3kg
NC CybTouch 8 touch screen in the swivel arm
NC controlled back gauge (5-1000mm) driven by ball screws
Safety light barrier for the rear compartment
Motorized cutting gap adjustment via the control
Side stop 1500mm with scale and T-slot
Two front support arms 1000mm
Transfer balls in the table for easier material handling
Hold-down with plastic caps to protect the material
Variable cutting length adjustment via the control
Folding finger guard 1000mm with Plexiglas inserts
Sheet metal slide in the back space
Cut line lighting with silhouette
Knife suitable for cutting stainless steel
Top knife with 2 and lower knife with 4 cutting edges
Electrical components from Siemens and Mitsubishi
Hydraulic components Bosch Rexroth and Hydac
Possible equipment options:

Pneu Automatic sheet metal holding systems
Front light barrier instead of finger guard
Adjustable angle stop
Cutting line display by laser
Servo motor for backgauge
Manual or automatic centralized lubrication
Air conditioner for the control cabinet
Oil cooler or oil warmer
Special colors
Replacement knives / special knives
